504 Pro G4 Baler

Features & Benefits

Netwrap system

Load and route netwrap with ease at the back of the baler with a rear-load netwrap system. Spread net edge-to-edge and adjust netwrap tension from the cab on a scale of 0 to 100 to maximize spread over the edges, depending on the type of netwrap. Plus, the net gauge on the Atlas Pro control system keeps track of how much net is left on the roll so you can focus on the windrow ahead of you.

17-knife chopping system

Choose your preferred cut length for optimizing bale density, silage quality, feed mixing time and digestibility with a 17-knife chopping system. Select eight or nine knives from Atlas Pro control system for a moderate cut length, all 17 knives for maximum processing, or lower both knife banks to bale without chopping.

Poly riser stripper bands

Spend more time baling hay and less time clearing out your pickup. The unique geometry of the patent-pending poly riser stripper bands promote crop stripping and minimize pickup wrapping.

Split gearbox

Baling tough crops? No problem. A 540 rpm or 1,000 rpm PTO tie into a split gearbox, running the pickup on one side and the chamber on the other to help spread the load to both sides of the baler and allow for the use of a cut-out clutch to help with longevity and torque.

Drop floor

The last thing anyone wants to be doing is clearing a plug from the pickup. The drop floor flexes during baling to help crop flow into the chamber with ease. If a plug does occur, operators can clear a plug from the cab with confidence by using tractor hydraulics to lower the floor, allowing crop to pass through so they can get back to baling.

Atlas Pro™ control system

Control the outcome of the bale from the convenience of the cab with the Atlas Pro control system. Monitor real-time bale and crop statistics and adjust based on moisture, crop and customer preference for up to 50 fields. Plus, control features like the knife banks, drop floor and net tension, all without ever leaving the seat.

Specifications

Compare Models
Show Metric
  • Bale Size

    • Bale Diameter 36 in - 60 in (91 cm - 150 cm)
    • Bale Width 48 in 121.9 cm
    • Maximum bale weight 2400 lbs 1088.6 kg
  • Dimensions and Weights

  • Bale Forming Chamber

  • Drive System

  • Tractor Requirements

  • Pickup

  • Control system

  • Density

  • Bale tie system

  • Features
