T955III Pipeline Trencher CE Certified

Features & Benefits

Full function remote control

Available with an optional wireless remote control that can provide full operator function remotely.

Low-speed, high-torque motor

Use the trenching machine more effectively with less wear due to its low-speed, high-torque, splined headshaft motor.

Standard remote

Decrease trencher teeth inspection and replacement maintenance time through a standard remote control that can start or stop the engine, raise or lower the trencher boom and rotate the chain at a slow speed.

Extra wide conveyor opening

Promote high-volume spoil removal with an extra-wide 30-in (76.2-cm) dirt conveyor opening that helps reduce jamming.

Rotary power trencher drive motor

A rotary power trencher drive motor and splined headshaft produce a lower speed and higher torque which provide superior ground penetration and low chain wear for better production results.

Optional warranty

Vermeer Vantage Track Extended Care Service Program offers an optional 3-year/3000-hour or 5-year/5000-hour heavy equipment warranty on the components of the closed-loop hydrostatic system.

Specifications

Compare Models
Show Metric
  • Transport Dimensions

    • Approach Angle 16 deg
    • Height Range 133" (337.8 cm)
    • Length with 40" (101.6 cm) End Idler and 6 ft (1.83 m) Boom 32.2 ft 9.8 m
    • Length with 40" (101.6 cm) End Idler and 8 ft (2.44 m) Boom 34.7 ft 10.6 m
    • Length with 40" (101.6 cm) End Idler and 10 ft (3.05 m) Boom 37.2 ft 11.3 m
    • Length with 40" (101.6 cm) End Idler and 12 ft (3.66 m) Boom 39.7 ft 12.1 m
    • Weight Range 78,000 lb - 109,000 lb (35,380.2 kg - 49,441.6 kg)
    • Width Ranges 114" (289.6 cm)
  • Engine - Option one

  • Engine - Option two

  • Tracks

  • Conveyor

  • Attachments

  • Cab

  • Hydraulic System

Attachments

Trencher

Trencher

    • Boom Depth Options 6 ', 8 ', 10 ', or 12 ' (1.8 m, 2.4 m, 3 m, or 3.7 m)
    • Sectionalized Boom Standard
    • Boom Top Rollers Optional
    • Minimum Chain Speed 316 ft/min 96.3 m/min
    • Show More down arrow
