VSR440 Single-screw Vertical Mixer

Features & Benefits

Processing ability

Achieve a thorough and consistently mixed ration with the VSR440 single-screw vertical mixer. Built to handle high-roughage rations, this mixer can process full bales or preprocessed material in a timely and flexible manner.

Bale containment

Less feed on the ground means less feed wasted. An optimized tub and screw design along with a bale containment kit minimize spillage during mixing or processing.

Containment kit

Help keep more roughage in the tub of the mixer and less on the ground with the standard bale containment kit. A chain hay ring around the rim of the tub helps to minimize spillage while still allowing operators the room they need to add feed ingredients to the tub.

Large tires

Focus on feeding — not getting your mixer stuck in adverse ground conditions. The tires on the VSR440 single-screw vertical mixer provide maximized flotation to help prevent ground damage.

Durable design

Extend machine life and minimize routine maintenance with durable components such as a heavy-duty planetary and 1/2-in (1.3-cm) AR200 screw flighting.

Optional high-screw rpm

Empty the mixer quickly and efficiently at the end of a load with optional high-screw rpm. A 48-rpm screw, along with two points of contact with the tub floor helps clean out the tub to make sure the ration gets in the bunk or on the curb — not left in the tub.

Efficient cleanout

Two points of contact along with an optional high-screw rpm help clean out the mixer quickly and efficiently at the end of the load.

Right-side tire access

Save time and frustration during maintenance on mixers equipped with a conveyor by stowing it for convenient access to the right-side tire.

Specifications

Compare Models
Show Metric
  • Dimensions and Weights

    • Loading height - standard 109 in 276.9 cm
    • Machine weight - standard 8570 lbs 3887.3 kg
    • Maximum net load 10000 lbs 4535.9 kg
    • Total length 197 in 500.4 cm
    • Transport width - 50-in folding conveyor extension 130 in 330.2 cm
    • Working width - 50-in folding conveyor extension 156 in 396.2 cm
    • Tires (retread) Standard 445/50R-22.5
  • Tub and screws

  • Discharge System

  • Tractor Requirements

  • Drive System

  • Scale system
